Once you decide to make a lot of PCBs using SMT technique, using reflowing instead of soldering - so that the entire board is 'soldered' at once. But to do that you'll need to deposit paste precisely on the pads. if you ever decide to make a few hundred boards especially those with very fine pitch type parts (say 0.4 or 0.5mm pitch) it is time to move to a framed stencil!
We are a printed circuit board fab house with stencil-making capabilities,We could export the Cream Top (or Bottom) layer from your PCB layout . If you want your PCB with panels made, we could suggest panel drawing with most econonical size, stencil size which is suitable for most of SMT machines.We will calculate the best stencil thickness (you want a thicker stencil for large-pitch parts and thinner for fine pitch so an average is taken)* and ship it the next day or together with your printed circuit board.
Caring Circuit is dedicated to providing the highest quality Laser Cut Stencils; with our rapid response, you will have your Stencil delivered on-time.
Our experienced staff can help with the design of your Stencil and apply industry standard IPC-7525A guidelines for designing your Stencil.
We have all of the standard frame sizes available and can also provide frameless systems. We also provide mini rework stencils along with BGA Repair/Re-balling Stencils. Try us out, we guarantee you will be satisfied.
Laser Cut Stencil Capabilities
Cutting Area x= 24” y=28”
Process cutting accuracy of +/- .0002” (+/- 5um) over the entire work area
Cut width .0015”
Cut Features as narrow as .002”
Utilizing the finest grain stainless material
Material Thickness from .002” (2mil) to .020” (20mil)
24-hour turnaround
9000 apertures/hour capability
Data: Gerber, HPGL, DPF and more..
