Frame Stencil  NO.:ST-001

frame SMT stencil together with PCB|Framed surface mount stencil
  • Product Name:Frame Stencil
  • Model No.:ST-001
  • Product Abstract:

    • PCB frame stencil together ship together with pcb after pcb fabrication,  with low cost, ship on time, CaringCircuit SMD Stencils are the best solution.

  • 【Printing】  【Close】

Details

Framed SMT Stencils or "glue- in " stencils are laser-cut solder paste stencils permanently mounted in a stencil frame using a mesh border to tightly stretch the stencil foil taut in the frame. Framed stencils are designed for high volume screen printing on printed circuit boards. Framed SMT stencils have smooth aperture walls and can be used for 16Mil pitch and blew and for Micro BGA's.

Surface Mount Stencil Parameters

Technology : Laser cut

Material : Stainless steel

Stencil thickness: .002-.016 inches

Minimum Cut Width: .002 inches

Available size of stencil :  37*47 cm    /    42*52 cm   /  55*55cm    /   55*65 cm     /      58*58 cm  /     73*73 cm

Aperture Tolerance: within 0.00025 inches

Allow for Fiducial Data: Yes

Allow For Panelized Data: Yes

Thickness of metal sheets standardly are 75μm, 100μm, 127μm, 150μm, 200μm.
Producible hole diameters

Advantage of buying pcb stencil from Caringcircuit

Save shipping cost and save time once you order stencil together with PCB.

PCB panel design and paste files generated together with stencil design.

Unique process for smooth aperture walls

Very clean laser-cut apertures

Excellent print performance

Excellent for high-volume stencil printing on PCB

Unique process creates permanent non-removable non-fading fiducial

All framed SMT stencils are double bonded to extreme wear

Two days turnaround leadtime.
